Disposable tableware equipment is a production equipment of fully degradable tableware with simplified structure, high production efficiency and using corn, corncob, rice fiber and other environmental protection materials as raw materials.

該設備構造性能特點有：由于擠出機擠出端直接螺連片材成型器，省略了輥壓成片機。格外是該C型片材成型器在設計上轉變了傳統機械設計中認為金屬腔體內的阻擋體在受壓條件下須平衡固定的思維，設計成一點與外體連接，通過適當增加連接處的厚度與寬度來保障機械強度，繼而直接的實現了C型片材成型。另外，擠出機擠出端口與片材成型器密閉螺連，玉米、玉米芯被推入螺桿碾壓推進之時產生了摩擦高溫，在物料被C型或"-"型縫槽擠出一接觸外界空氣，即形成了爆米花效應而自然的膨化，省去了傳統工藝中的發泡過程。

The structure and performance characteristics of the equipment are as follows: due to the direct screw connection of the sheet former at the extrusion end of the extruder, the roll forming machine is omitted. In particular, the design of the C-type sheet former has changed the thinking that the barrier in the metal cavity must be balanced and fixed under pressure in the traditional mechanical design, and is designed to be connected with the outer body at one point, so as to ensure the mechanical strength by appropriately increasing the thickness and width of the connection, and then directly realize the C-type sheet forming. In addition, the extrusion port of the extruder is tightly screwed with the sheet former, and the friction high temperature is generated when the corn and corn cob are pushed into the screw for rolling and pushing. When the material is extruded by the C-type or "-" type slot and contacts the external air, it forms the popcorn effect and natural expansion, eliminating the foaming process in the traditional process.

而且推進螺桿設計成雙線漸深螺紋構成的雙頭擠出結構，增加了工效。生產過程為全物理變化，產品用后可全降解或作飼料，對環保具有積極的推動作用。

Moreover, the propulsion screw is designed into a double headed extrusion structure composed of double thread and gradually deep thread, which increases the work efficiency. The production process is full physical change. The product can be fully degraded or used as feed after use, which plays a positive role in promoting environmental protection.

該一次性餐具設備的工作原理：采用降解的植物原料，比如玉米、玉米芯、稻谷纖維等，從擠出機料斗經攪拌進入推進螺杄，物料在螺杄與螺套之間擠碾向前推進，當螺杄達到一定轉速時，物料在碾擠摩擦過程之中溫度上升，其由C型成片器的出口端擠出時，一接觸外界空氣，即會自然膨化，省略了傳統工藝中的發泡工序。冷卻水的通道是為規避物料溫度太高而焦糊。

Working principle of the disposable tableware equipment: degraded plant raw materials, such as corn, corncob, rice fiber, etc., are mixed from the extruder hopper into the propulsion screw, and the materials are extruded and pushed forward between the screw and the screw sleeve. When the screw reaches a certain speed, the temperature of the materials rises during the process of grinding and extrusion friction, and it is extruded from the outlet end of the C-type flaker, Once exposed to external air, it will expand naturally, omitting the foaming process in the traditional process. The channel of cooling water is to avoid burning due to too high material temperature.

變頻器1.3控制電機轉速，以在較高擠出速度與合適溫度中調到越佳轉速。從擠出機岀來的膨化片材，切割成段后的片材經過霧化冷濕機再經過蒸汽加濕機的加濕攤平并且柔軟化增加了韌性之后，傳送到成型機進行成型。成型后的產品送到干燥涂膠臺，對干燥后的產品表面涂刷可降解、耐高熱溫、沒損害的膠水，經涂膠的產品再送遠紅外烘干機上快速烘干，末后經包裝與后便可出廠。

Frequency converter 1.3 controls the speed of the motor to adjust the speed at higher extrusion speed and suitable temperature. After the expanded sheet from the extruder is cut into sections, it is sent to the forming machine for forming after being humidified and flattened by the atomization cold humidifier, and then softened and softened by the steam humidifier to increase the toughness. The formed products are sent to the drying gluing table. The surface of the dried products is coated with degradable, high temperature resistant and undamaged glue. The glued products are sent to the far-infrared dryer for rapid drying. Finally, they can leave the factory after packaging and disinfection.
